P02BF BMW Fault Code

Check P02BF OBD Fault Code Reason
Description:

Engine Coolant Temperature (ECT) Circuit High Input Indicates the sensor signal is greater than Self-Test maximum. The ECT sensor maximum is 4.6 volts or -50 C (-58 F). Note on some vehicles that are not equipped with an ECT sensor, CHT can be used and can set this DTC. Open circuit in harness Sensor signal short to power Damaged PCM Improper harness connection Damaged sensor ECT V PID reading greater than 4.6 volts with key ON and engine OFF or during any engine operating mode indicates a hard fault.

P02BF Code Symptoms :

See P02BF in engine

OBD P02BF code and tailpipe testing are two different approaches to identify vehicles in need of repair. The OBD system looks for broken or malfunctioning emissions control components and P02BF, while tailpipe tests sample a vehicle's exhaust to see if it is above or below certain prescribed limits. Given the robust nature of today's emissions control components, it is entirely possible for an individual component to malfunction without leading to an immediate increase in emissions at the tailpipe.

In such cases, other components (like the catalyst) can temporarily compensate for the part that is broken however, these other components can only do double duty for so long before they, too, begin to malfunction. In addition, OBD also monitors for and other malfunctions in the fuel system problems that traditional tailpipe tests were not designed to identify. Most state and local areas also include a gas cap pressure test as part of an emission inspection.

Diagnosis And Repairing P02BF

P02BF OBD2 reports a sensor fault, replacement of the sensor is unlikely to resolve the underlying problem. The fault is most likely to be caused by the systems that the sensor is monitoring, but might even be caused by the wiring to the sensor itself.

How to fix P02BF code ?

See P02BF repair manual
  • Camshaft advance mechanism binding (VCT unit)
  • Damaged camshaft position (CMP) sensor
  • Engine Control Module (ECM)
  • Variable Camshaft Timing (VCT) position circuit poor electrical connection

At this point we are assuming that the fuses and relays are good. You will need to locate the PCM/TCM and the power input signal circuit using your vehicle information source.

Unplug the connector from the PCM/TCM, place the ignition switch in the ON position, and probe the appropriate circuit with the positive test lead of the DVOM.
